Item

Quantity

Name

Description

1.

20000

Switch Block & Motor Plate

Common small high-volume parts, most of the machining is unattended.

2.

600

End Lever

Machined from aluminum, then black anodized, demonstrates K6 capabilities for machining complex surfaces.

3.

7000

Electrical Housing

Machined from an 8.5 inch long aluminum extrusion (0.093 wall), brush finish applied, and black anodized.  This part shown saw 5 ECOs in 3 years with only a 5% total price increase.

4.

6000

Electrical Back Pad

Machined on all sides from a fiberglass sheet

5.

3200

Filter Head

This part demonstrates how K6 effectively uses machining center techniques to reduce cost for what would normally be considered lathe work such as threads (buttress and NPT) and o-ring grooves.

6.

400

Electronics Fittings

Note the long thin prongs and slots.  (turning done by another shop)

7.

4

Electronic Enclosure

Machined from a 2 inch thick solid aluminum block to a wall thickness of 0.060, this part demonstrates our ability to handle challenging, short-run orders.

8.

4

Fitting

Mates to item 7

9.

200

Mated Pieces

Machined from Delrin in mated pairs
